High Lift Pallet Truck

₹37,500.00

Model No – SI-HPT107

This Hand Pallet Truck features an ergonomically designed handle, ensuring maximum comfort and ease of use even during extended periods of material handling.

  • Capacity – 0.5 to 1 ton
  • Height – 800-1000 mm
  • Fork (mm) – 1150 (L) x 550 (W)
SKU: 188 Category: Tags: , , , , , , ,

Description

material handling hand pallet truck india – saideep ind.

Pioneer Leader of Hand Pallet Truck & Material Handling Equipment Manufacturer India

enhance after-sales service

Maintenance and AMC will also be available.

Capacity 0.5 – 1 Ton
LIFT 90MM / STROKE (800-1000 MM / Height)
Fork 150 MM
Min. Fork Height 90 MM
Max. Fork Height 800-1000 MM
Fork Length 1150 MM
Fork Width 550 MM
Lower Speed Continuously Variable
Hydraulic Unit 1 Nos. Vertical Mounted Hyd. EN-8 ground and hard chrome plated piston Hand Operated Pump with Honned Hyd. Cylinder & Hard Chrome Plated Piston Rod. Hyd. Pump Includes ‘Pu’ & Plate Based
Teflon Oil Seals With Built In Overload Protection Valve.
Wheels

Wheel Material – Nylon

2 Nos. 170 x 50 mm. Size Wheels at Front (Handle) Side & 2 Nos. 80 X 70 mm. Size Load Roller Wheels at Rear Side.
All Wheels – Heavy Duty nylon Wheels – Contains Double Ball Bearings For Easy Movement.
Handle 3 Lever Position Handle (Lift/Lock/Release)
Paint Entire structure shall be powder coated or auto finish painted

Request Call-Back

+91-8735984066

Additional information

Dimensions 1150 × 550 × 800 mm
Load Capacity

1 Ton, 500-1000 Kgs.
Color

Yellow Golden
